SetDoubleBlock
andMonitorTool
at location
BYTHE
NUMBERS
Five
Non-Intrusive Isolation
steps toa
SetPlugModule#1–
100%
LinePressure
BleedDownLPSide to
50%
ofHPSide
SetPlugModule#2–
50%
LinePressure
BleedDownLPSide to
Ambient
Pressure
Offshore pipelinemaintenance typically falls into one of four categories:
valve replacement, tie-in, riser repair,or heavy lift protection.
During these types ofmaintenance,operators rely on non-intrusive inline
isolationmethods to protect their people,achieve compliance,andmitigate
reductions to production. Themost common isolation is theDNV-certified
double block andmonitormethod,as seen here.
DNV-CertifiedDoubleBlock
andMonitor IsolationMethod
1
2
3
4
5
LOW
LINEPRESSURE
HIGH
LINEPRESSURE
ANNULUSPRESSURE
Monitoring and
TrackingModule
DP
*
Monitored
DP
*
Monitored
DP
*
Monitored
*
DifferentialPressure
Plug
Module #1
Plug
Module #2
Control
Module
Annulus pressuremonitored
for verification of both seals
50%
LINEPRESSURE
DNVRecommendedPractice forPipeline
SubseaRepairCriteria (DNV-RP-F113/3):
. Each barriermust be able to retain full line pressure
. Independent locking system
. Sealmust be independently tested
. Ability tomonitor line integrity
. Sealsmust be independent
from each other
Through the use
of independently operated isolation
barriers and continuousmonitoring,
the system allows high-pressure
pipeline operators to carry out remedial
pipelinework in a safe,controlled,and
monitored environment.
